Specifications
General
Color
Black
Manufacturer Color
Black
Type
Built-In
Cooktop
Burners/Elements
4
Power Output
• Zone one: 2100W/3500W
• Zone two: 2100W/3500W
• Zone three: 1200W/1800W
• Zone four: 2100W/3500W
• Bridge zone: 3300W Max
• Zone two: 2100W/3500W
• Zone three: 1200W/1800W
• Zone four: 2100W/3500W
• Bridge zone: 3300W Max
Burner/Element Size
• Zone One: 8.26" x 7.08"
• Zone two: 8.26" x 7.08"
• Zone three: 5.7"
• Zone four: 8.26"
• Bridge zone: 14.50"L x 8.31"W
• Zone two: 8.26" x 7.08"
• Zone three: 5.7"
• Zone four: 8.26"
• Bridge zone: 14.50"L x 8.31"W
Elements
Smoothtop
Surface Features
• Zone One: Location: Left Reat
• Zone two: Location: Left Front
• Zone three: Location: Middle Rear
• Zone four: Location: Right Front
• Bridge zone: Location: Left Front + Left Rear
• Zone two: Location: Left Front
• Zone three: Location: Middle Rear
• Zone four: Location: Right Front
• Bridge zone: Location: Left Front + Left Rear
Features
Additional Information
Control Type: Glass Touch
Control Location: Front Center
Display: White LED
Power Adjustment Levels: 1-9
Power Boost Mode "P": All Zones
Warm "A": All Zones
Simmer "A": All Zones
Melt "A": All Zones
Simmer Enhancer Cooking Zones: All Zones
1-99 Minute Timer/Zone: All Zones
Automatic Pan Detection: All Zones
Residual Heat Indicator "H": All Zones
Control Lock
Auto Turn Off
Ventilation Spacers: 4
Cooling Zone: right rear (8.0" x 21.0")
Spoon Rest: 6.0" x 21.0"
Dishwasher Safe: Both
Electrical Information
Information
• Total Wattage: 7500W
• Voltage: 240V, 60Hz
• Amps: 30A
• Voltage: 240V, 60Hz
• Amps: 30A
Certifications and Approvals
Information
• Agency Certifications: ETL, CETL, FCC, CSA
• Approved for Combination Installation with Sharp Appliances
• Approved for Combination Installation with Sharp Appliances
Dimensions
Class Width
30"
Width
30 inch(es) / 76.2 cm
Height
2.5 inch(es) / 6.35 cm
Depth
21 inch(es) / 53.34 cm
Weight
44 lb(s) / 19.96 kg
Additional Dimensions
Cutout Dimensions: 29 3/16" x 4 1/2" x 19 5/8"
Shipping Dimensions
Width
34.75 inch(es) / 88.27 cm
Height
9.5 inch(es) / 24.13 cm
Depth
25 inch(es) / 63.5 cm
Volume
1.73 cu. ft.
Warranty
Warranty
• Parts: 1 year limited
• Labor: 1 year limited
• Labor: 1 year limited
UPC
UPC#
074000621602
